Key Specification
Max. Data Rate
300 Mbps at 2.4 GHz,
867 Mbps at 5GHz
867 Mbps at 5GHz
Dimensions (W x D x H)
165 mm x 86 mm x 29 mm
(6.50 in. x 3.39 in. x 1.14 in.)
(mounting brackets excluded)
(6.50 in. x 3.39 in. x 1.14 in.)
(mounting brackets excluded)
Net Weight
0.236 kg (0.52 lbs.)
Service Ports
1 x 1G SC port
3 x 10/100/1000BASE-T Ethernet ports
1 x phone port
3 x 10/100/1000BASE-T Ethernet ports
1 x phone port
PoE
Not Support
Local Power
Support,
1 x DC power connector (12 V/1.5 A)
1 x DC power connector (12 V/1.5 A)
Operating Temperature
0°C to 40°C
(32°F to 104°F)
(32°F to 104°F)
Bi-directional Optical Sub-Assembly (BOSA) Transmit Power
0 dB to 3 dB
Bi-directional Optical Sub-Assembly (BOSA) Receiver Sensitivity
–8 dB to –28 dB
Warranty
3 years
Certification
CE, CB, SDPPI, MIC, NBTC, SIRIM
